Description:

INTERNAL DIMENSIONS:                                EXTERNAL DIMENSIONS:

Width                       800mm                                Width                   1450mm

Depth                      1500mm                              Depth                   2040mm

Height to crown      1200mm                              Height to crown   1950mm

Bats per level          6                                         Mass approx.      1700kg

INSULATION: 114mm of 2300 grade insulating bricks backed by 50mm of calcium silicate board.

CURRENT DRAWN: 3 x 67 A

ELECTRICAL POWER : 45kw

COOLING: Through ports in the floor and vents in the arch.

These kilns are robustly built in heavy steel sections.

They are exceptionally easy to transport and travel well by road, rail or sea.

No commissioning is required as the kiln is 100% complete when it leaves our works.
