Specifications
Chamber Dimensions: 1180 wide x 1140 deep x 1230 high (to top of wall)
Current: 3 x 75 Amps
Power: 50 kW
Mass: 280 kg

Features:
The frame is constructed of robust steel sections and plate.
Cladding is 4mm thick galvanized lattice to provide support without forming a barrier against which corrosive vapours condense.
The lining comprises 114mm insulating brick with deep grooves to accommodate the elements and 50mm of ceramic fibre based insulating
boards.
Elements are made of Kanthal A1 3.75mm wire
Elements terminate on copper busbars supported by ceramic mountings.
Three cooling vents in arched roof have swing open doors.
Cooling air may be introduced by under floor cooling ports.
Fires 30m ² of 300mm x 300mm floor tiles every 48 hours.
A TOHO P9 programmable controller, capable of storing and executing 8 x 8 step programs, is fitted as standard.
