Information
Features
- Low Cost
- Excellent temperature uniformity
- Elements are cast into refractory lining and in this way muffling the elements from the atmosphere.
- Digital PID setpoint controller or micro-processor based programmable controllers are standard.
- Double skin construction for low external temperature
- Vented chamber, which extracts fumes by opening a chamber vent.
- Plug type door acts as a trap for radiated heat minimizing door temperature.
Specifications
| MODEL | LEF014 | LEF005 |
|
CHAMBER |
|
180 mm 180 mm 150 mm |
|
EXTERNAL |
460 mm 460 mm 640 mm |
510 mm 380 mm 355 mm |
| TEMPERATURE (maximum operating) |
950°C | 950°C |
| VOLTAGE | 220 volt 50 Hz |
220 volt 50 Hz |
| CONNECTION |
1 phase neutral |
1 phase neutral earth |
| POWER SUPPLY CONNECTION (delay-action fuse) |
12A 2.6 kW |
9A 2.0 kW |
| (by customer) | Automatic circuit breaker | |
| WEIGHT (packed) | 50 kg | 30 kg |
| BOTTOM LOAD (max. recommended) |
6 kg | 2 kg |
| VOLUME OF WORKING CHAMBER |
1.4 litres | 0.5 litres |
| CONTROLLERS |
Digital setpoint controllers with PID control functions or multi step micro |
|
