Specifications
External Dimensions
Overall Rail length       10 550 mm
Length doors closed     3 110 mm
Width                             1 720 mm  including electrical box
Height with vents           2 200 mm

Internal Dimensions
Length of trolley             2 514 mm
Width of trolley                  952 mm
Width of kiln                   1 054 mm
Height of top of wall       1 140 mm
Height to top of arch +/- 1 342 mm

Shelf Size: 450 x 330 x 16mm – 14 shelves per level
Mass Approx: 2700 kg
Power: 96.5 kW
Current: 145 Amps per phase @ 240 V

These kilns are robustly built in heavy steel sections.
Frames are mild steel, epoxy coated.
Cars run on roller bearing wheels and engineered rails.
Cladding is 444 grade stainless steel.
Cooling is through four large vents in the arch.
Doors close onto ceramic fibre door seals.
The insulation comprises 114mm insulating brick (imported) and 50mm secondary insulation (usually ceramic fibre based).
Elements are Kanthal A1
Large electrical boxes have hinged covers
All wiring is silicone insulated
Under floor seals are mechanical and totally effective
