Specifications
Chamber width: 800 mm
Chamber depth: 1 500 mm
Chamber height: 1 200 mm
Electrical power: 45 kW
Current: 3 x 68 Amps
Power supply required: 3 phase and neutral
External width: 1 450 mm
Rail length:  4 000 mm

Frames are mild steel, epoxy coated
Cars run on roller bearing wheels and engineered rails
Cladding is 316 grade stainless steel
Vents are provided under cars and in the arch
Doors close onto ceramic fibre door seals
The insulation comprises 114 mm insulation brick (imported) and 50 mm secondary insulation (usually ceramic fibre based)
Elements are Kanthal A1
Large electrical boxes have hinged covers
All wiring is silicone insulated
Under floor seals are mechanical and total effective.
